CPU
3 axes
CPU
ARM11
RAM
128M
CPU Clock Speed
600M
Flash
256M
Monitor Dimension
8 inches LED
Monitor Resolution
800*600
I/Os
Standard: 16/16; Extended terminal board: 10/8 (cascade connection)
Performance Indicator
The product stands EMI/Electrical fast transient immunity/Surge immunity tests and conforms to the fourth grade protection standards of GB/T 17626.5-2008.
Resistance to vibration conforms to the GB/T 2423.10-2008 Standards.
The product stands rigid temperature tests and conforms to the industrial standards of GB/T 2423.102-2008.
Analog Voltage Output
0-10V
Tool Magazine Type
Linear tool magazine, Disk-type tool magazine
Tool Measurement Mode
Auto measurement, Manual measurement
Tool Measurement Type
Fixed calibration, Mobile calibration, First calibration & Calibration after tool change
Compensation Type
Screw error compensation, Backlash compensation, AQE compensation, Tool compensation
Internet(Ethernet)
LAN communication, Front USB interface, Two-way transmission between the system and PC
Supported File Format
*.g/*.nc/*.u??/*.demo/*.iso/*.eng/*.cut/*.dxf/*.plt/*.txt
WCS Setting
Supporting WCS G54-G59
Processing Technology
Array function, Mirror&rotate, Multi-layer machining, Cycle machining
Convenient Operations
Handwheel guide, Breakpoint resume, Tool selection
Interpolation Algorithms
T-type, S-type
Chinese,English
CNC Software Alarm
Alarms of program error, operation error, over-travel error, PLC error and IO communication error
